Introduction:

Your direct source for quality optical transceivers and connectivity solutions.
Fiberdyne Labs Optical Transceivers are standard compliant modules, which are used in a variety of Ethernet equipment, such as:
• - Data Centers
• - 5G Wireless Application Fronthaul
• - Midhaul and Backhaul
• - Telecom Networks Application
• - Metro, DCI and 5G Backhaul Coherent Transmission
• - Intra Data Center Connectivity
As the name implies, the SFP modules simply plug into the available equipment ports. If your requirements change, you simply unplug your existing SFP module, and plug-in your new module. Fiberdyne Labs offers a wide variety of SFP modules (i.e. CWDM, DWDM and BiDi) to meet your requirements. New York
Complete Product Portfolio of 1G, 10G, 25G, 40G, 100G, 200G, 400G and 800G.

New York



Quick Links:
∙ CFP
∙ 16G FC
∙ 32G FC
∙ 25G SFP28
∙ 50G QSFP28 Single Lambda
∙ 200G QSFP56



5G Wireless Application Fronthaul, Midhaul and Backhaul



CFP 100G/112G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) CFP FDN-CFP-100G-LR4 CFP LR4 1296-1309nm LWDM DFB PIN -4.3/-2.5 4.5/2.9 -10.6/-8.8 4.5/4 9 10km 0~70 FDN-CFP-100G-ER4 CFP ER4 1296-1309nm LWDM DFB APD -2.7/-2.9 2.9 -20.7 4.5 12 40km 0~70 FDN-CFP-100G-ZR4 CFP ZR4 1296-1309nm LWDM DFB APD -2.7/-2.9 2.9 -20.7 4.5 15 80km 0~70 FDN-CFP2-100G-LR4 CFP2 LR4 1296-1309nm LWDM DFB PIN -4.3/-2.5 4.5/2.9 -10.6/-8.8 4.5/2.9 6 10km 0~70 FDN-CFP2-100G-ER4 CFP2 ER4 1296-1309nm LWDM DFB APD -2.7/-2.9 2.9 -20.7 4.5 9 40km 0~70 FDN-CFP2-100G-ZR4 CFP2 ZR4 1296-1309nm LWDM DFB APD -2.7/-2.9 2.9 -20.7 4.5 12 80km 0~70 FDN-CFP4-100G-LR4 CFP4 LR4 1296-1309nm LWDM DFB PIN -2.5/-4.3 2.9/4.5 8.8 2.9 6 10km 0~70



FC 16G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) 16G FC FDL-FC16-SW SFP+SR FC 850nm VCSEL PIN -7.8 -0.5 -10.5 0 1.0 100m 0~70 FDL-FC16-LW SFP+LR FC 1310nm DFB PIN -5 -0.5 -12 0.5 1.5 10km 0~70 FDL-FC16-EW SFP+ER FC 1550nm EML PIN -1 3 -14 0.5 2.5 40km 0~70 FDL-FC16-CXX-10 SFP+ ER CWDM CWDM EML PIN -1 3 -14 0.5 2.5 40km 0~70 FDL-FC16-CXX-40 SFP+ ER DWDM DWDM EML PIN -1 3 -14 0.5 2.5 40km 0~70 FDL-FC16-DXX-10 SFP+ FC BIDI 1330nm DFB PIN -3 2 -12 0.5 1.5 10km 0~70 FDL-FC16-DXX-30 SFP+ FC BIDI 1270nm DFB PIN -3 2 -12 0.5 1.5 10km 0~70



FC 32G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) 32G FC FDL-FC32-SW SFP28 32G FC SR 850nm VCSEL PIN -6.2 2.0 -10.3 2.0 1.0 100m 0~70 FDL-FC32-LW SFP28 32G FC LR 1310nm DFB PIN -5.0 2.0 -13.3 2.0 1.2 10km 0~70 FDL-FC32-EW SFP28 32G FC ER 1310nm DML APD 0 6 -16 -3 1.5 40km 0~70



SFP28 25G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) 25G SFP28 FDL-SFP28-SR SFP28 SR 850nm VCSEL PIN -8.4 2.4 -10.3 2.4 1.0 100m 0~70 FDL-SFP28-LR SFP28 LR 1310nm DFB PIN -7.0 2.0 -13.3 2.0 1.0 10km 0~70 FDL-SFP28-ER SFP28 ER 1310nm EML ADP -3.0 6.0 -21.0 -4.0 1.5 40km 0~70 FDL-SFP28-SRI SFP28 SR IT 850nm VCSEL PIN -8.4 2.4 -10.3 2.4 1.0 100m -40~85 FDL-SFP28-LRLI SFP28 LR Lite IT 1310nm DFB PIN -7.0 2.0 -10.5 2.0 1.2 300m -40~85 FDL-SFP28-LRI SFP28 LR IT 1310nm DFB PIN -7.0 2.0 -13.3 2.0 1.2 10km -40~85 FDL-SFP28-2733-10 SFP28LRBIDIIT 1270/1330nm DFB PIN -7.0 2.0 -13.3 2.0 1.0 10km -40~85 FDL-SFP28-CWI SFP28LRCWDMIT DFB CWDM PIN -2.0 6.0 -13.3 2.5 1.5 10km -40~85 FDL-SFP28-LWI SFP28 LRLWDMIT DFB LWDM PIN -3.0 3.0 -15.3 3.0 1.5 10km -40~85 FDL-SFP28-IWI SFP28 IRLWDMIT EML LWDM APD -2.0 6.0 -21.0 -4.0 1.8 20km -40~85 FDL-SFP28-DWI SFP28 LR DWDM IT EML DWDM PIN -2.0 6.0 -13.3 -2.5 1.5 10km -40~85 FDL-SFP28-ERI SFP28 ER IT 1310nm EML APD -3.0 6.0 -21.0 -4.0 1.8 40km -40~85 FDL-SFP28-TD-LR SFP28 LRTunable 48Channel (191.3~196.0THz) APD 0.0 4.0 -16.0 -0.0 2.5 10km -0~70



QSFP28 Single Lambda 50G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) 50G QSFP28 Single Lambda FDL-QSFP28-50G-LR QSFP28 LR (PAM4) 1310nm EML PIN -4.5 4.2 -10.8 4.2 3.5 10km 0~70 FDL-QSFP28-50G-ER QSFP28 ER (PAM4) 1310nm EML APD -0.4 6.6 -17.6 -3.4 3.5 40km 0~70 FDL-QSFP28-LRBD QSFP28 LR BIDI (PAM4) 1310nm EML PIN -4.5 4.2 -10.8 -4.2 3.5 10km 0~70 FDL-QSFP28-ERBD QSFP28 ER BIDI (PAM4) 1310nm EML APD -7.5 6.6 -17.6 -3.4 3.5 40km 0~70 FDL-QSFP56-SR QSFP56 SR 850nm VCSEL PIN -4.5 4.0 N/A 4.0 1.5 100m 0~70 FDL-QSFP56-LR QSFP56 LR 1310nm DFB PIN 0.4 4.2 -10.8 4.2 1.8 10km 0~70



QSFP56 200G Data Rate

P/N Product Description TX RX TX_Min (dBm) TX_Max (dBm) RX_Min (dBm) RX_Max (dBm) Power Consumption Reach Temperature (degC) 200G QSFP56 FDL-Q56-200G-SR4 QSFP56 SR4 850nm VCSEL PIN -6.5 4.0 -8.4 4.0 5.5 100m 0~70 FDL-Q56-200G-FR4 QSFP56 FR4 EML CWDM4 PIN -4.2 4.7 -8.2 4.7 5.0 2km 0~70 FDL-Q56-200G-LR4 QSFP56 LR4 (hermetic package) EML LWDM PIN -3.4 5.3 -9.7 5.3 12.0 10km 0~70 FDL-Q56-200G-ER4 QSFP56 ER4 (hermetic package) EML LWDM APD 0.0 6.5 -15.5 -3.0 12.0 40km 0~70
